sales@bitsfrombytes.com +44 (0)1275 873792 Document No D100246

BFB 3000 Operations manual

Initial Z height set

step

• Make sure the Z adjuster is protruding approximately

10mm above the print bed (Fig.1)

• Enter “HOME TOOL HEAD” and let the head home itself.

• Move the tool head to a position over the rear left of the

print bed

• Try to slide the scraper blade (supplied in the tool kit)

between the bed and the end of the nozzles (Fig.2)

scraper blade

slides between

the end of the

nozzle and the

bed with little

resistance

Fig.1

Z adjuster

Print bed

Fig.2

If the blade will not fit – go to

step

If the gap is too big - go to 3

step
